CPD series Clamp-on Ultrasonic Flow Sensor / Flow Meter

The CPD series clamp-on ultrasonic flow sensor/flow meters boast a compact design with an integrated display and circuit system, facilitating seamless flow measurement and intuitive data monitoring.

Designed for easy clamping onto rigid plastic tubing, the CPD series clamp-on ultrasonic flow sensor/flow meters delivers an accuracy of up to ±2%.

Furthermore, it can detect bubbles and solid particles within the liquid.

With the non-invasive design, the CPD series ultrasonic flow sensor/flow meter guarantees that no flow contamination occurs during the measurement process.It is support non-invasive flow rate measurement of water, pure water, cleaning water, acids, chemical, CMP slurry, oil, beverages, alcohols, etc.

It is particularly well-suited for applications requiring stringent hygiene and cleanliness standards, such as biopharmaceuticals, medical devices, and industrial automation.

Request a demo

Product Features

High Accuracy：±2%

The flow rate measurement accuracy is essential for applications requiring stringent quality control and process optimization.

Hygienic Safety

The CPD clamp-on flow sensor/flow meter support non-invasive flow rate measurement, which significantly reduces contamination risk, makes it ideal for hygienic sensitive applications in the industrial automation process.

Bi-Directional Measurement

The CPD clamp-on flow sensor/flow meter support accurately calculating fluid volume and detecting air bubbles. The CPD ultrasonic flow sensor can perform volume dosing and function as a flow switch, providing a multifunctional solution that enhances operational versatility.

Compact Design

The CPD clamp-on flow sensor/flow meter has embedded circuit eliminates, streamlining installation and reducing space requirements. The compact design simplifies setup while maintaining stable flow rate measurement performance.

No Blockages

The CPD clamp-on flow sensor/flow meter support non-invasive flow rate measurement without blockage or dead zones, reduces potential system strain.

Output Mode

The CPD clamp on flow sensor / flow meter support multi-output methods that facilitate seamless integration with the control systems.

Product Selection

Product Model

Flow Range

Tubing OD

Tubing ID

CPD025NB

Max:0-5000mL/min

1/4”(6.4mm)

3~5mm
CPD038NB

Max:0-15000mL/min

3/8”(9~10mm)

5~8mm
CPD050NB

Max:0-30000mL/min

1/2”(12~13mm)

6~11mm

Specifications

Measurable liquids

Water, acids, pure water, drinks, oil, paints, chemicals, slurry etc., containing no or few solid particles

Accuracy

2% RD(Reading) and adding zero offset;±0.1% f.s.(full scale)

Calibration

Default calibration: 22±3°C, water

Tube Materials

Plastics

Input Voltage

12-30 VDC

Current Consumption

Less than 20mA (without external load)

Interface

8-pin push-pull plug

Fluid Temperature

0°C to 90°C

Ambient Temperature

0°C to 60°C

Shield

Wire grounding

Inputs and outputs

• RS485
• 3 Current output selectable: 4-20mA,0-20mA,0-24mA;,
• 2 Voltage output selectable: 0-5V,0-10V
• 0-20KHz frequency output
• 3 Digital output selectable: NPN, PNP, PUSH-PULL
• Digital input, grounding time should be more than 20 ms

Accessory

8-core shielded cable, default length 1.5 m

Optional Accessory

• USB data converter, for connecting a sensor to a computer
• Flow sensor tool kit with display, allows up to 3 sensors to be connected to a computer simultaneously
• The flow sensor display screen connects to a single sensor and routes the sensor cable out
• Data cable, 3 meters, with push-pull connectors on ends, connects the flow display to the sensor
