TGD series In-line Ultrasonic Flow Sensor

The TGD series inline ultrasonic flow sensors/meters feature an integrated design with a built-in display and circuitry, allowing for direct flow measurement and intuitive flow data monitoring.

The sensors/meters integrate into the customer's existing fluid systems through internationally standardized tubing fittings, with an accuracy of up to ±2%, providing high precision, high sensitivity, and high reliability.

TGD series consists of straight tubing with no moving parts and dead spots, making it resistant to wear and scaliness, easy to clean, and minimal pressure loss.

Compared to clamp-on sensors/meters, the TGD series sensor calibration does not depend on the tubing material and diameter, enabling immediate measurement upon integration into the system. They are widely used in filling and spraying applications, battery manufacuturing device, liquid cooling, industrial automation systems, and more.

Applications

Industrial Automation: Filling equipment, spraying equipment, cooling systems, and lubrication systems.

New Energy Industry: Such as CMP, cleaning systems, and cooling systems.

Water Treatment and Wastewater Treatment Systems.

Product Features

No blockage


The internal measuring tubing is unobstructed, effectively reducing pressure loss and the risk of blockage.


Reliable and Durable


The measuring tubing is made from corrosion-resistant materials, suitable for complex working environments.


Integrated Design


Built-in circuitry offers a compact size and ease of installation.


Convenient Integration


Multiple output modes allow for quick integration into the customer’s existing tubing monitoring system.


Product Selection

Product Model
Flow Range
Connection
  • TGD015N
    0-4L/min
    Double union joint(DN15)
  • TGD020N
    0-100L/min
    Double union joint (DN20)
  • TGD025N
    0-240L/min
    Double union joint (DN25)
  • TGD032N
    0-240L/min
    Double union joint (DN32)
  • TGD050N
    0-1,000L/min
    Double union joint (DN50)

Specifications

Measurable liquids
Water, blood, beverages, gasoline, paint, etc., with little to no solid particles.

Accuracy

1% plus zero drift.

Enclosure Material
Plastic

Input Voltage

12-30 VDC
Current
Less than 20mA (no external load).
Interface
 5-pin push-pull connector.
Fluid Temperature

0°C to 60°C

Storage Temperature
-20°C to 70°C.
Shielding
Grounded wiring
Inputs and outputs
  • • RS485
  • • Current output modes selectable: 4-20mA,0-20mA,0-24mA
  • • Pulse output with three selectable modes: NPN, PNP, PUSH-PULL
  • *The current output and pulse output share pins and can be configured for one or the other based on application needs.

Accessory

 5-pin shielded cable, default length 1.5 meters. Two each of coupling accessories and sealing rings.

Optional Accessories
  • • USB data converter,allowing a single sensor to connect to a computer.
  • • Flow sensor toolkit, with a display, allowing up to three sensors to connect to a computer simultaneously.
  • • Flow display device, connecting one sensor and routing the sensor cable
  • • Data cable, 3 meters long, with push-pull connectors on both ends, connecting the flow display device and the sensor.
